The BMD-1 is one of the truly innovative weapons systems that came out of the Soviet Union, and still stands out as one of the most fascinating concepts they ever managed to get into production.
The Soviet Airborne Forces, or VDV, were created in the 1930s and considered an elite force even then. But when they entered into combat in WWII, in places such as the disastrous drop at Vyazma, they found themselves at the mercy of heavily armed and armored opponents. Attempts to provide them with "flying" tanks � T-60 tanks with wings and engines or ones that could be airdropped with the paratroopers � came to naught. Postwar, the Soviets did develop the diminutive ASU-57 with a powerful 57mm antitank gun, but it had no armor protection of which to speak. The later ASU-85 gave them more punch, but was much larger at around 16 metric tons. They also were poorly suited to do anything in regard to transport of troops.
Three years after the new armored infantry-fighting vehicle BMP appeared and went into service, a new design was created by the designers at the Volgograd Tractor Factory as Object 915. This was a lightweight vehicle that used the complete weapons system and turret from the BMP on a specially designed chassis that could be rigged for airdrop. To enhance its mobility, the new chassis had an adjustable pneumatic suspension that could be set to provide from 100 to 450 mm of ground clearance (the former was for hiding the vehicle or rigging it for air drop, the latter was the maximum setting for crossing rough terrain.) The new machine used a 240 HP diesel engine and weighed only 7.6 metric tons.
This vehicle fit the concepts of Soviet VDV theoretician and commanding general Vasiliy F. Margelov, who knew that airborne forces dropped deep in the enemy's rear area needed a combat vehicle to do their job of raiding and destroying lines of communication up right. He worked out the design of the Kentavr (centaur) system for airdrops, which used parachutes with rocket braking to drop heavy vehicles safely. To ensure that this worked right, Margelov wanted the crew � gunner and driver-mechanic � to drop inside the vehicle to prove that it worked. He used two cosmonaut seats rigged inside the vehicle, and to prove to the Soviet Army it worked, had one of his favorite commanders and his own son (by then a VDV officer as well) drop in the first manned test. It worked, and the Soviets were off to the races with the new vehicle, dubbed BMD-1 (D for "desant", a word used for troops that leave a vehicle or aircraft to assault an objective.)
The BMD-1 served from 1968 when it entered production until 1985, when it was upgraded across the board into the BMD-1P. The P differed from the first production models in adding new radio equipment, new sights and replacing the over-the-barrel 9M14 Malyutka ATGM (AT-3 SAGGER) with a new mount for the 9M111 Fagot or 9M113 Konkurs (AT-4 SPIGOT or AT-5 SPANDREL).
In 1985 there was also a new model, the BMD-2, introduced with a 30mm 2A42 cannon similar to that in the BMP-2. But the turret was tiny and this system does not seem to be as popular or widespread as the BMD-1/1P. A new vehicle created in the late 1980s, the BMD-3, was accepted as a replacement but so far few have been purchased by the Russian Army. The BMD-1/1P fought in Afghanistan and Chechnya with the Soviet Union and Russia, and in Kuwait with the Iraqi Army.
www.ipmsottawa.ca/topic.asp?TOPIC_ID=96&FORUM_ID=13&CAT_ID=3&Forum_Title=Armour+kit+reviews+%26+articles&Topic_Title=Eastern+Express+1%2F35+BTR%2DD+Airborne+Links+Vehicle
In 1965, when the Soviets felt that their airborne forces would be cut to pieces if they landed in the rear of NATO troops with no support, legendary airborne General Margelov created his "centaur" - the BMD-1 or airborne infantry combat vehicle. Mounting a complete BMP-1 turret on a very lightweight hull, it created an 8 metric ton vehicle that could be airdropped, provide room under armor (albeit quite cramped) for six men, and provide airborne forces with overwhelming firepower against rear echelon forces.
In Airborne and Airmobile Forces, Russian, Peter Antill writes:
Post-War Developments
The VDV ended the war in some disarray. The operations had been bad fiascos, but the units had fought with courage and heroism, with some 196 soldiers receiving the Hero of the Soviet Union medal. In 1946 the VDV was transferred from the Air Force to direct control of the Ministry of Defence to serve as a strategic reserve. It languished over the next decade, while the role of the airborne divisions was examined in light of the experience gained by all sides during the war. The Soviets concluded that with the exception of the German operations in 1940 and 1941, most airborne operations were failures or made no real contribution to conventional campaigns. Successes were only forthcoming when facing weak or demoralised opponents, and when facing quality opposition the results were usually catastrophic (as at Arnhem). Despite this there remained a conviction that airborne forces did have a role to play in dropping behind enemy lines and causing mayhem in the enemy's rear areas. In 1956 the VDV was switched to the Ground Forces and came under the command of General V. F. Margelov (a wartime hero of the Naval Infantry), who set about modernisation with determination. The first results were the introduction of the An-8 transport (followed by the An-12) and the increase in firepower with the new B10 82mm Recoilless Rifle (followed by the B11 107mm Recoilless Rifle) in the mid-1950's, and the RPG-2 around the same time. What really helped was the development of light armoured vehicles that could be dropped with the paratroopers. The Soviets had realised that previous operations had ". . . . ended with the landing of the force. Manoeuvre was largely at the speed of the infantryman. Soviet recognition of this weakness formed the key to further development of this force. In the Soviet concept of the vosdushnii desant (airborne assault) the landing of the force is simply the beginning of the operation." [note 2] The first of these were the ASU-76 and ASU-57, the latter of which entered service in 1955. This was followed by the ASU-85 (based on the PT-76 scout tank) in 1960 and could be airlifted by the new An-12. With the embarrassment over the Cuban missile crisis, the Politburo decided that the Soviet Union should substantially enhance its ability to project military power abroad. As a result, the VDV was again transferred back to direct Ministry of Defence control in 1964.
Sightseeing in Prague and Kabul
The invasion of Czechoslovakia was designated Operation Danube. The Soviet Army formed a Strategic Direction composed of three Fronts (Central, Carpathian and Southern) and the VDV mobilised two of its divisions, of which the 103rd Guards Desant Division was to deliver the coup de main against Prague, with elements of the Polish 6th Airborne Division designated to take the airfield at Pardubice. On the evening of the 20th August 1968, an unscheduled Aeroflotte An-24 aircraft made an unscheduled landing at Ruzyme Airport at around 2030 hrs, and was soon followed by an aircraft from Lvov in the Ukraine at about midnight, which unloaded a number of Soviet 'civilians' who talked with Czech officials and then departed. As the troops of the three Fronts crossed the Czech border, the 'civilians' took up positions around the airport. At around 0200 hrs, two An-12 aircraft, escorted by MiG-21 fighters, landed at the airport, and two companies of desantniki (about 180 men) were disgorged and took over from the 'civilians'. After the airfield was secured, the command An-24, which had been the first aircraft to arrive, ordered the rest of the 103rd Guards Desant Division to start landing. This contained a number of ASU-85s and armoured personnel carriers, and a special assault group was to take the presidential palace, with the rest of the division seizing key points around the city. Not long after, the lead elements of the Central Front, the 6th Guards and 35th Motor Rifle Divisions entered Prague. For the invasion of Afghanistan, a larger VDV force was allocated than for Czechoslovakia, presumably because of the greater expectation of resistance. The VDV were to again provide the coup de main against Kabul, and were to eliminate the Afghan President, Hafizullah Amin, and replace him with a puppet regime under Babrak Karmal. One regiment was to be used from the 103rd and 104th Guards Desant Divisions, as well as the entire 105th Guards Desant Division in the operation. In early December 1979, the Soviets transferred the regiments from the 103rd and 104th into the country to assist in controlling Bagram airport just outside Kabul. Meanwhile, Soviet advisors all over the country began attempts to paralyse the armed forces. On the 24th December, the VDV forces at Bagram seized control of the airfield and the main elements of the 105th Guards began to arrive from their base in the neighbouring Turkestan Military District. The main Soviet forces began crossing the border on the 25th December, and the VDV assembled the main battle group to assault the presidential palace. After a brief but intense battle, the Soviets took the palace, and then spread out to take key locations around Kabul, and other population centres, such as Kandahar. Later in 1980, the airborne forces were reorganised, with the 105th Guards being disbanded, apart from the 345th Guards Airborne Regiment which became an independant air assault regiment, and both it and the 103rd Guards Desant Division were stationed at Bagram during the Afghan conflict.
Going Solo
It was its reorganisation as a semi-autonomous branch of the Soviet Armed Forces that marked a major shift in the VDV's nature. During the 1960's the Soviet Army had embarked on a shift in doctrine and tactics that emphasised the ability to fight on a nuclear battlefield (particularly in a European conflict). The VDV realised that they could be very useful in a theatre devastated by nuclear weapons but the troops could not survive in contaminated areas unprotected. So the VDV decided to follow the same route as the Ground Forces and develop a smaller lighter version of the BMP, which appeared in 1970 as the BMD (Boyevaya Maschina Desantnaya - Airborne Combat Vehicle). This marked the move from the light infantry role, to a mechanised air assault force, as the BMD equipped one, and eventually all three regiments (making around 320 BMDs) in a division. The BMD is a smaller version of the BMP, sharing the same turret and engine, but having a new hull and suspension design. The internal configuration is different and is more cramped. There are stations for three crewmembers (driver, gunner and commander) and for three passengers. The BMD-1 shares the same 73mm low pressure gun with the BMP-1 and has a revolving magazine of forty rounds, with an AT-3 'Sagger' missile launcher on top of the main gun. The engine and transmission are housed at the rear, and the suspension can be lowered and locked down for air transportation. Fuel is carried by a tank in the right rear corner of the vehicle and was supplemented on later models by two small external tanks. It is fully NBC protected, and has armour sufficient to withstand small arms and artillery shrapnel. However, "its light weight and small size have resulted in some performance and handling constraints. The armament system shares the same shortcomings as that on the BMP: the Malyutka (the Russian name for the AT-3 'Sagger') missile is difficult to aim due to its primitive guidance system, especially from a moving armoured vehicle; the main 73mm gun is short ranged; and its finned projectile is vulnerable to cross-winds to a greater extent than more conventional ammunition." [note 3] There were also problems with the poorly supported fuel tank, fragile transmission and poor ventilation when the crew fires the main gun. Many of these problems have been addressed to a greater or lesser extent in the BMD-1 M1973 model or the heavily redesigned BMD-2 which featured new grill vents, an internal redesign, new roadwheels, a 30mm automatic cannon in place of the 73mm gun, and an AT-4 'Spigot' or AT-5 'Spandrel' launcher in place of the AT-3 'Sagger', and first appeared in 1980. While it was initially unclear whether the BMD-2 had the complete turret of the BMP-2, it was later discovered that the turret was a new more compact design housing just the gunner (on the left), day / night sight, anti-aircraft sight, the 30mm 2A42 stabilised cannon and co-axial 7.62mm PKT machine gun. In 1990, a new airborne assault vehicle entered service, with the first production units going to the airborne forces, with delivery to the naval infantry to follow. The BMD-3 has a new chassis design and is fitted with the complete turret of the BMP-2. The vehicle is reported to have much better amphibious capability (hence the acquisition by the Naval Infantry), a more spacious interior, better firepower and improved command and control (due to the two man turret). The BMD-3 can be dropped complete with its crew of seven and the IL-76 can carry three such vehicles. An AG-17 grenade launcher is mounted on the front left of the vehicle and a 5.45mm RPKS machine gun on the right bow. The engine is a 2V-06 water-cooled diesel developing 450 bhp, giving a high power-to-weight ratio of 34 hp / tonne. The transmission is hydromechanical and features five forward and five reverse gears with a hydraulic steering unit. The vehicle has five rubber tyred road wheels, a large drive sprocket at the rear, an idler at the front and four return rollers.
"Armor across country" by Jim Dietz www.jamesdietz.com
NOTE: the U.S. Army and marines had successfully employed Light/Medium tanks in Vietnam from 1960-1973 particularly with the former's fabulous Armored CAValry (ACAV) units:
Mounted Combat in Vietnam by General Don Starry
The Smoking Gun: Light Tanks/APCs More Mobile than Medium-Weight Ones, and M113 Gavins were the MOST effective weapon in soft open and vegetated closed terrain terrain Vietnam--NOT the helicopter
Noted armor historian and WW2 Hobart's "Funnies" (combat engineer tanks) combat veteran Major Kenneth Macksey wrote in his 1991 book, Tank versus Tank, page 167:
"The Vietnam War was a war dominated by infantry and firepower, in which AFVs, initially, were relegated to a limited part because the Vietnamese possessed virtually no tanks of their own and their enemies persisted in thinking of the struggle as a guerrilla war in country unsuitable to tanks. Not until 1967, when the United States carried out a feasibility study, was it discovered that tanks could move in 61 per cent of the country during the dry season and in 46 per cent in the wet; and that APCs could move in 65 per cent of Vietnam all year round. Thereafter the forces of South Vietnam rapidly raised their armor content to be matched only meagerly, however, by their opponents. As a result, AFVs were almost entirely employed in support of infantry; the principal threat to them was posed by mines and infantry anti-tank weapons, including ATGW. Yet AFVs were rated the most cost-effective weapon system for a country where the helicopter was enjoying a great vogue on the battlefield."
What this means is as follows:
M113 Gavins (light tank/APCs) 8 PSI ground pressure = 65% of Vietnam dry/wet 24/7/365
M48 Pattons (medium tanks) 11.2-12.2 PSI * ground pressure = 46% of Vietnam wet season
.............................................................................................................61% of Vietnam dry season
A light mechanized infantry with M113 Gavin light tank/APCs would fight mounted and/or with these vehicles nearby rendering fire support and ammunition, water, food transport 65% of everywhere to include swimming across lakes/rivers; only 35% of the terrain was dismounted foot-travel only--we fight the enemy from positions of overmatching SUPERIORITY with more firepower and units of fire, as well protection from his fires.
If we medium-mechanize or motorize with high ground pressure FCS 30-ton tanks (12 PSI) or 20-ton Stryker truck (30 PSI) wheels 54% of a soft, wet terrain like Vietnam will be NO-GO to them and be enclaves for the ENEMY to reside in safety lest we fight them M16 vs. AK47 & RPG even or at a disadvantage. The enemy could attack us during the wet winters and withdraw without fear of us pursuing them lest we get stuck or stick to roads where they ambush us with land mines. The FCS will only be mobile in firm, open terrain types, and the Stryker, road-bound unless very firm, dry, open terrain is available. Neither FCS or Strykers can swim.
Sub-Notes
* http://afvdb.50megs.com/usa/m48patton.html
Tank futurist, Ralph Zumbro (who was there in combat in Vietnam doing bold 2D/3D air/ground maneuver) has a web site that offers many insights:
So the U.S. Army should not have been surprised at the Russians gobbling up countries flying in light tank forces; the question is why didn't the U.S. create its own powerful Airborne/Air Assault forces with light tanks to counter communist expansion since they had plenty of M113 Gavins and M551 Sheridans?
