Toyota Corolla FX GT
1993 AE101 20v 4A-GE
|
MOTOR
|
LINKS |
Factory Specifications:
1587cc 4 cylinder DOHC 'silvertop'
81mm bore, 77mm stroke, 10.5:1 compression
5 valves per cylinder, variable valve timing
4 throttle system
160 bhp @ 7400rpm, 120 lb/ft @ 5200rpm
Suggested fuel 100 octane!
Modifications:
TRD (Toyota Racing Developments) Platinum spark plugs
Performance panel air filter
Larger bore exhaust system, chrome tail pipes
There are 2 types of inlet manifold on the silvertop - one which resembles a teardrop shape fitted to facelift (93.5 on) AE101s, the other more like an oval with a cutout extending from the top of each port fitted to early (up to 93.5) AE101s. The teardrop shape far outflows the oval. See the above link for pics and further info.
