[CPUID]
| CPU-Z | |
| Binaries | |
| CPU-Z version | 2.12.0.x32 |
| Processors | |
| CPU Groups | 1 |
| CPU Group 0 | 2 threads, mask=0xFFFF |
| Number of sockets | 1 |
| Number of threads | 2 |
| APICs | |
| Socket 0 | |
| -- Core 0 (ID 0) | |
| -- Thread 0 | 0 |
| -- Core 1 (ID 1) | |
| -- Thread 1 | 1 |
| Timers | |
| ACPI timer | 3.580 MHz |
| Perf timer | 2929.700 MHz |
| Sys timer | 1.000 KHz |
| Processors Information | |
| Socket 1 | ID = 0 |
| Number of cores | 2 (max 2) |
| Number of threads | 2 (max 2) |
| Manufacturer | GenuineIntel |
| Name | Intel Pentium E6500 |
| Codename | Wolfdale |
| Specification | Pentium(R) Dual-Core CPU E6500 @ 2.93GHz |
| Package (platform ID) | Socket 775 LGA (0x0) |
| CPUID | 6.7.A |
| Extended CPUID | 6.17 |
| Core Stepping | R0 |
| Technology | 45 nm |
| TDP Limit | 65.0 Watts |
| Core Speed | 2929.9 MHz |
| Multiplier x Bus Speed | 11.0 x 266.4 MHz |
| Base frequency (cores) | 266.4 MHz |
| Rated Bus speed | 1065.4 MHz |
| Stock frequency | 2933 MHz |
| Instructions sets | MMX, SSE, SSE2, SSE3, SSSE3, EM64T, VT-x |
| Microcode Revision | 0xA07 |
| L1 Data cache | 2 x 32 KB (8-way, 64-byte line) |
| L1 Instruction cache | 2 x 32 KB (8-way, 64-byte line) |
| L2 cache | 2 MB (8-way, 64-byte line) |
| Max CPUID level | 0000000Dh |
| Max CPUID ext. level | 80000008h |
| FID/VID Control | yes |
| FID range | 6.0x - 11.0x |
| Max VID | 1.288 V |
| Temperature 0 | 49 degC (120 degF) (Cores (Max)) |
| Temperature 1 | 49 degC (120 degF) (Core #0) |
| Temperature 2 | 49 degC (120 degF) (Core #1) |
| Clock Speed 0 | 2929.89 MHz (Core #0) |
| Clock Speed 1 | 1598.12 MHz (Core #1) |
| Clock Speed 2 | 266.35 MHz (CPU BCLK) |
| Clock Speed 3 | n.a. (SOC BCLK) |
| Core 0 max ratio | (effective) 11.00 |
| Core 1 max ratio | (effective) 11.00 |
| Chipset | |
| Northbridge | Intel P45/P43/G45/G43 rev. A3 |
| Southbridge | Intel 82801JR (ICH10R) rev. 00 |
| Bus Specification | PCI-Express 2.0 (5.0 GT/s) |
| Graphic Interface | PCI-Express 1.0 |
| PCI-E Link Width | x16 (max 16x) |
| PCI-E Link Speed | 2.5 GT/s (max 2.5 GT/s) |
| Memory Type | DDR2 |
| Memory Size | 4 GBytes |
| Channels | Single |
| Memory Frequency | 399.5 MHz (2:3) |
| CAS# latency (CL) | 6.0 |
| RAS# to CAS# delay (tRCD) | 6 |
| RAS# Precharge (tRP) | 6 |
| Cycle Time (tRAS) | 18 |
| Row Refresh Cycle Time (tRFC) | 52 |
| Command Rate (CR) | 2T |
| Host Bridge | 0x2E20 |
| Memory SPD | |
| DIMM # | 1 |
| SMBus address | 0x50 |
| Memory type | DDR2 |
| Module format | Regular UDIMM |
| Module Manufacturer(ID) | Nanya Technology (7F7F7F0B0000000000000000000000) |
| Size | 2048 MBytes |
| Max bandwidth | PC2-6400 (400 MHz) |
| Part number | NT2GT64U8HD0BY-AD |
| Serial number | 4AC6EC14 |
| Manufacturing date | Week 05/Year 10 |
| Number of banks | 8 |
| Data width | 64 bits |
| Correction | None |
| Nominal Voltage | 1.80 Volts |
| EPP | no |
| XMP | no |
| AMP | no |
| EXPO | no |
| JEDEC timings table | CL-tRCD-tRP-tRAS-tRC @ frequency |
| JEDEC #1 | 4.0-4-4-12-16 @ 266 MHz |
| JEDEC #2 | 5.0-5-5-15-20 @ 333 MHz |
| JEDEC #3 | 6.0-6-6-18-24 @ 400 MHz |
| DIMM # | 2 |
| SMBus address | 0x51 |
| Memory type | DDR2 |
| Module format | Regular UDIMM |
| Module Manufacturer(ID) | Nanya Technology (7F7F7F0B0000000000000000000000) |
| Size | 2048 MBytes |
| Max bandwidth | PC2-6400 (400 MHz) |
| Part number | NT2GT64U8HD0BY-AD |
| Serial number | EAD6EC16 |
| Manufacturing date | Week 05/Year 10 |
| Number of banks | 8 |
| Data width | 64 bits |
| Correction | None |
| Nominal Voltage | 1.80 Volts |
| EPP | no |
| XMP | no |
| AMP | no |
| EXPO | no |
| JEDEC timings table | CL-tRCD-tRP-tRAS-tRC @ frequency |
| JEDEC #1 | 4.0-4-4-12-16 @ 266 MHz |
| JEDEC #2 | 5.0-5-5-15-20 @ 333 MHz |
| JEDEC #3 | 6.0-6-6-18-24 @ 400 MHz |
| Monitoring | |
| Mainboard Model | P43T-C51 (MS-7519) (0x000003F5 - 0x1272C720) |
| LPCIO | |
| LPCIO Vendor | Fintek |
| LPCIO Model | F71882F |
| LPCIO Vendor ID | 0x1934 |
| LPCIO Chip ID | 0x541 |
| Hardware Monitors | |
| Hardware monitor | Fintek F71882F |
| Voltage 0 | 3.28 Volts [0xCD] (+3.3V) |
| Voltage 1 | 1.15 Volts [0x90] (CPU VCORE) |
| Voltage 2 | 0.87 Volts [0x6D] (DRAM) |
| Voltage 3 | 4.92 Volts [0x75] (+5V) |
| Voltage 4 | 12.14 Volts [0x8A] (+12V) |
| Voltage 8 | 3.18 Volts [0xC7] (VBAT) |
| Temperature 0 | 25 degC (76 degF) [0x19] (CPU) |
| Temperature 1 | 31 degC (87 degF) [0x1F] (TMPIN1) |
| Fan 0 | 1545 RPM [0x3CB] (FANIN0) |
| Fan PWM 0 | 100 pc [0xFF] (CPU) |
| Fan PWM 1 | 60 pc [0x99] (System Fan 1) |
| Fan PWM 2 | 50 pc [0x80] (System Fan 2) |
| Fan PWM 3 | 50 pc [0x80] (System Fan 3) |
| Hardware monitor | NVIDIA NVAPI |
| Clock Speed 0 | 135.00 MHz [0x87] (Graphics) |
| Clock Speed 1 | 324.00 MHz [0x144] (Memory) |
| Clock Speed 2 | 270.00 MHz [0x10E] (Processor) |
| PCI Devices | |
| Description | Host Bridge |
| Location | bus 0 (0x00), device 0 (0x00), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x2E20 |
| Revision ID | 0x03 |
| PCI header | |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x00 |
| Int. Pin | 0x00 |
| PCI capability | |
| Caps class | Vendor Dependant |
| Caps offset | 0xE0 |
| Description | PCI to PCI Bridge |
| Location | bus 0 (0x00), device 1 (0x01), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x2E21 |
| Revision ID | 0x03 |
| PCI header | |
| Primary bus | 0x00 |
| Secondary bus | 0x01 |
| Int. Line | 0x10 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | Subsystem Vendor |
| Caps offset | 0x88 |
| SubVendor ID | 0x1462 (MSI) |
| SubSystem ID | 0x7519 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x80 |
| Caps version | 1.2 |
| PCI capability | |
| Caps class | Message Signalled Interrupts |
| Caps offset | 0x90 |
| PCI capability | |
| Caps class | PCI Express |
| Caps offset | 0xA0 |
| Device type | Root Port of PCI-E Root Complex |
| Port | 2 |
| Caps version | 2.0 |
| Physical slot | #0 |
| Presence detect | yes |
| Link width | 16x (max 16x) |
| Link speed | 2.5 GT/s (max 5.0 GT/s) |
| Description | USB Controller (UHCI) |
| Location | bus 0 (0x00), device 26 (0x1A), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A37 |
| Revision ID | 0x00 |
| PCI header | |
| Address 4 (port) | 0x0000CC00 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x10 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x50 |
| Description | USB Controller (UHCI) |
| Location | bus 0 (0x00), device 26 (0x1A), function 1 (0x01) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A38 |
| Revision ID | 0x00 |
| PCI header | |
| Address 4 (port) | 0x0000C880 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x15 |
| Int. Pin | 0x02 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x50 |
| Description | USB Controller (UHCI) |
| Location | bus 0 (0x00), device 26 (0x1A), function 2 (0x02) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A39 |
| Revision ID | 0x00 |
| PCI header | |
| Address 4 (port) | 0x0000C800 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x13 |
| Int. Pin | 0x04 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x50 |
| Description | USB 2.0 Controller (EHCI) |
| Location | bus 0 (0x00), device 26 (0x1A), function 7 (0x07) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A3C |
| Revision ID | 0x00 |
| PCI header | |
| Address 0 (memory) | 0xFCFFE000 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x12 |
| Int. Pin | 0x03 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x50 |
| Caps version | 1.1 |
| PCI capability | |
| Caps class | Debug Port |
| Caps offset | 0x58 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x98 |
| Description | PCI to PCI Bridge |
| Location | bus 0 (0x00), device 28 (0x1C), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A40 |
| Revision ID | 0x00 |
| PCI header | |
| Primary bus | 0x00 |
| Secondary bus | 0x02 |
| Int. Line | 0x11 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | PCI Express |
| Caps offset | 0x40 |
| Device type | Root Port of PCI-E Root Complex |
| Port | 1 |
| Caps version | 1.0 |
| Physical slot | #0 |
| Presence detect | yes |
| Link width | 1x (max 1x) |
| Link speed | 2.5 GT/s (max 2.5 GT/s) |
| PCI capability | |
| Caps class | Message Signalled Interrupts |
| Caps offset | 0x80 |
| PCI capability | |
| Caps class | Subsystem Vendor |
| Caps offset | 0x90 |
| SubVendor ID | 0x1462 (MSI) |
| SubSystem ID | 0x7519 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0xA0 |
| Caps version | 1.1 |
| Description | PCI to PCI Bridge |
| Location | bus 0 (0x00), device 28 (0x1C), function 1 (0x01) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A42 |
| Revision ID | 0x00 |
| PCI header | |
| Primary bus | 0x00 |
| Secondary bus | 0x03 |
| Int. Line | 0x10 |
| Int. Pin | 0x02 |
| PCI capability | |
| Caps class | PCI Express |
| Caps offset | 0x40 |
| Device type | Root Port of PCI-E Root Complex |
| Port | 2 |
| Caps version | 1.0 |
| Physical slot | #0 |
| Presence detect | no |
| Link width | 0x (max 1x) |
| Link speed | 2.5 GT/s (max 2.5 GT/s) |
| PCI capability | |
| Caps class | Message Signalled Interrupts |
| Caps offset | 0x80 |
| PCI capability | |
| Caps class | Subsystem Vendor |
| Caps offset | 0x90 |
| SubVendor ID | 0x1462 (MSI) |
| SubSystem ID | 0x7519 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0xA0 |
| Caps version | 1.1 |
| Description | USB Controller (UHCI) |
| Location | bus 0 (0x00), device 29 (0x1D), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A34 |
| Revision ID | 0x00 |
| PCI header | |
| Address 4 (port) | 0x0000C480 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x17 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x50 |
| Description | USB Controller (UHCI) |
| Location | bus 0 (0x00), device 29 (0x1D), function 1 (0x01) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A35 |
| Revision ID | 0x00 |
| PCI header | |
| Address 4 (port) | 0x0000C400 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x13 |
| Int. Pin | 0x02 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x50 |
| Description | USB Controller (UHCI) |
| Location | bus 0 (0x00), device 29 (0x1D), function 2 (0x02) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A36 |
| Revision ID | 0x00 |
| PCI header | |
| Address 4 (port) | 0x0000C080 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x12 |
| Int. Pin | 0x03 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x50 |
| Description | USB 2.0 Controller (EHCI) |
| Location | bus 0 (0x00), device 29 (0x1D), function 7 (0x07) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A3A |
| Revision ID | 0x00 |
| PCI header | |
| Address 0 (memory) | 0xFCFFC000 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x17 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x50 |
| Caps version | 1.1 |
| PCI capability | |
| Caps class | Debug Port |
| Caps offset | 0x58 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0x98 |
| Description | PCI to PCI Bridge |
| Location | bus 0 (0x00), device 30 (0x1E), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x244E |
| Revision ID | 0x90 |
| PCI header | |
| Primary bus | 0x00 |
| Secondary bus | 0x04 |
| Int. Line | 0xFF |
| Int. Pin | 0x00 |
| PCI capability | |
| Caps class | Subsystem Vendor |
| Caps offset | 0x50 |
| SubVendor ID | 0x1462 (MSI) |
| SubSystem ID | 0x7519 |
| Description | PCI to ISA Bridge |
| Location | bus 0 (0x00), device 31 (0x1F), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A18 |
| Revision ID | 0x00 |
| PCI header | |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x00 |
| Int. Pin | 0x00 |
| PCI capability | |
| Caps class | Vendor Dependant |
| Caps offset | 0xE0 |
| Description | IDE Controller |
| Location | bus 0 (0x00), device 31 (0x1F), function 2 (0x02) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A20 |
| Revision ID | 0x00 |
| PCI header | |
| Address 0 (port) | 0x0000C000 |
| Address 1 (port) | 0x0000BC00 |
| Address 2 (port) | 0x0000B880 |
| Address 3 (port) | 0x0000B800 |
| Address 4 (port) | 0x0000B480 |
| Address 5 (port) | 0x0000B400 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x13 |
| Int. Pin | 0x02 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x70 |
| Caps version | 1.2 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0xB0 |
| Description | SMBus Controller |
| Location | bus 0 (0x00), device 31 (0x1F), function 3 (0x03) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A30 |
| Revision ID | 0x00 |
| PCI header | |
| Address 0 (memory) | 0x00000000FCFFBC04 |
| Address 4 (port) | 0x00000400 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x0E |
| Int. Pin | 0x03 |
| Description | IDE Controller |
| Location | bus 0 (0x00), device 31 (0x1F), function 5 (0x05) |
| Common header | |
| Vendor ID | 0x8086 (Intel) |
| Model ID | 0x3A26 |
| Revision ID | 0x00 |
| PCI header | |
| Address 0 (port) | 0x0000B000 |
| Address 1 (port) | 0x0000AC00 |
| Address 2 (port) | 0x0000A880 |
| Address 3 (port) | 0x0000A800 |
| Address 4 (port) | 0x0000A480 |
| Address 5 (port) | 0x0000A400 |
| Subvendor ID | 0x1462 (MSI) |
| Subsystem ID | 0x7519 |
| Int. Line | 0x13 |
| Int. Pin | 0x02 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x70 |
| Caps version | 1.2 |
| PCI capability | |
| Caps class | 0x13 |
| Caps offset | 0xB0 |
| Description | VGA Controller |
| Location | bus 1 (0x01), device 0 (0x00), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x10DE (NVIDIA) |
| Model ID | 0x0CA3 |
| Revision ID | 0xA2 |
| PCI header | |
| Address 0 (memory) | 0xFD000000 |
| Address 1 (memory) | 0x00000000D000000C |
| Address 3 (memory) | 0x00000000CE00000C |
| Address 5 (port) | 0x0000DC00 |
| Subvendor ID | 0x0000 |
| Subsystem ID | 0x0000 |
| Int. Line | 0x10 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x60 |
| Caps version | 1.2 |
| PCI capability | |
| Caps class | Message Signalled Interrupts |
| Caps offset | 0x68 |
| PCI capability | |
| Caps class | PCI Express |
| Caps offset | 0x78 |
| Device type | PCI-E Endpoint Device |
| Port | 0 |
| Caps version | 2.0 |
| Link width | 16x (max 16x) |
| Link speed | 2.5 GT/s (max 2.5 GT/s) |
| PCI capability | |
| Caps class | Vendor Dependant |
| Caps offset | 0xB4 |
| Description | High Definition Audio (HDA) |
| Location | bus 1 (0x01), device 0 (0x00), function 1 (0x01) |
| Common header | |
| Vendor ID | 0x10DE (NVIDIA) |
| Model ID | 0x0BE4 |
| Revision ID | 0xA1 |
| PCI header | |
| Address 0 (memory) | 0xFEA7C000 |
| Subvendor ID | 0x0000 |
| Subsystem ID | 0x0000 |
| Int. Line | 0x11 |
| Int. Pin | 0x02 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x60 |
| Caps version | 1.2 |
| PCI capability | |
| Caps class | Message Signalled Interrupts |
| Caps offset | 0x68 |
| PCI capability | |
| Caps class | PCI Express |
| Caps offset | 0x78 |
| Device type | PCI-E Endpoint Device |
| Port | 0 |
| Caps version | 2.0 |
| Link width | 16x (max 16x) |
| Link speed | 2.5 GT/s (max 2.5 GT/s) |
| Description | Communication Device |
| Location | bus 4 (0x04), device 0 (0x00), function 0 (0x00) |
| Common header | |
| Vendor ID | 0xE159 |
| Model ID | 0x0001 |
| Revision ID | 0x00 |
| PCI header | |
| Address 0 (port) | 0x0000E800 |
| Address 1 (memory) | 0xFEBFF000 |
| Subvendor ID | 0x1212 |
| Subsystem ID | 0x0002 |
| Int. Line | 0x0A |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x40 |
| Caps version | 1.1 |
| Description | Audio device |
| Location | bus 4 (0x04), device 5 (0x05), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x1274 |
| Model ID | 0x5880 |
| Revision ID | 0x02 |
| PCI header | |
| Address 0 (port) | 0x0000EC00 |
| Subvendor ID | 0x1274 |
| Subsystem ID | 0x2003 |
| Int. Line | 0x15 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0xDC |
| Caps version | 1.0 |
| Description | Ethernet Controller |
| Location | bus 4 (0x04), device 6 (0x06), function 0 (0x00) |
| Common header | |
| Vendor ID | 0x10EC (Realtek) |
| Model ID | 0x8139 |
| Revision ID | 0x10 |
| PCI header | |
| Address 0 (port) | 0x0000E400 |
| Address 1 (memory) | 0xFEBFEC00 |
| Subvendor ID | 0x10EC (Realtek) |
| Subsystem ID | 0x8139 |
| Int. Line | 0x16 |
| Int. Pin | 0x01 |
| PCI capability | |
| Caps class | Power Management |
| Caps offset | 0x50 |
| Caps version | 1.1 |
| DMI | |
| DMI BIOS | |
| vendor | American Megatrends Inc. |
| version | V2.6 |
| date | 07/15/2010 |
| ROM size | 1024 KB |
| DMI System Information | |
| manufacturer | MICRO-STAR INTERNATIONAL CO.LTD |
| product | MS-7519 |
| version | 1.0 |
| serial | To Be Filled By O.E.M. |
| UUID | {00000000-0000-0000-0000-406186F07C13} |
| SKU | To Be Filled By O.E.M. |
| family | To Be Filled By O.E.M. |
| DMI Baseboard | |
| vendor | MICRO-STAR INTERNATIONAL CO.LTD |
| model | P43T-C51 (MS-7519) |
| revision | 1.0 |
| serial | To be filled by O.E.M. |
| DMI System Enclosure | |
| manufacturer | MICRO-STAR INTERNATIONAL CO.LTD |
| chassis type | Desktop |
| chassis serial | To Be Filled By O.E.M. |
| DMI Processor | |
| manufacturer | Intel |
| model | Pentium(R) Dual-Core CPU E6500 @ 2.93GHz |
| clock speed | 2933.0 MHz |
| FSB speed | 267.0 MHz |
| multiplier | 11.0x |
| max clock speed | 2933.0 MHz |
| DMI Memory Controller | |
| correction | 64-bit ECC |
| Max module size | 4096 MBytes |
| DMI Memory Module | |
| designation | DIMM1 |
| size | 2048 MBytes (double bank) |
| DMI Memory Module | |
| designation | DIMM2 |
| size | 2048 MBytes (double bank) |
| DMI Memory Module | |
| designation | DIMM3 |
| DMI Memory Module | |
| designation | DIMM4 |
| DMI Port Connector | |
| designation | PS1 (internal) |
| designation | PS2 Mouse (external) |
| port type | Mouse Port |
| connector | PS/2 |
| DMI Port Connector | |
| designation | PS1 (internal) |
| designation | PS2 Keyboard (external) |
| port type | Keyboard Port |
| connector | PS/2 |
| DMI Port Connector | |
| designation | COM1 (internal) |
| designation | COM (external) |
| port type | Serial Port 16550A |
| connector | DB-9 male |
| DMI Port Connector | |
| designation | JACK1 (internal) |
| designation | Audio Mic In (external) |
| port type | Audio Port |
| connector | Mini Jack (headphones) |
| DMI Port Connector | |
| designation | JACK1 (internal) |
| designation | Audio Line In (external) |
| port type | Audio Port |
| connector | Mini Jack (headphones) |
| DMI Port Connector | |
| designation | JACK1 (internal) |
| designation | Audio Line Out (external) |
| port type | Audio Port |
| connector | Mini Jack (headphones) |
| DMI Port Connector | |
| designation | USB1 (internal) |
| designation | USB1 (external) |
| port type | USB |
| connector | Access Bus (USB) |
| DMI Port Connector | |
| designation | USB1 (internal) |
| designation | USB2 (external) |
| port type | USB |
| connector | Access Bus (USB) |
| DMI Port Connector | |
| designation | LAN_USB1 (internal) |
| designation | USB3 (external) |
| port type | USB |
| connector | Access Bus (USB) |
| DMI Port Connector | |
| designation | LAN_USB1 (internal) |
| designation | USB4 (external) |
| port type | USB |
| connector | Access Bus (USB) |
| DMI Port Connector | |
| designation | LAN_USB1 (internal) |
| designation | LAN (external) |
| port type | Network Port |
| connector | RJ-45 |
| DMI Port Connector | |
| designation | VGA1 (internal) |
| designation | Monitor (external) |
| port type | Video Port |
| connector | DB-15 female |
| DMI Port Connector | |
| designation | JCOM1 (internal) |
| port type | Serial Port 16550A |
| DMI Port Connector | |
| designation | JBAT1 (internal) |
| DMI Port Connector | |
| designation | CD_IN1 (internal) |
| port type | Audio Port |
| connector | On Board Sound Input From CD-ROM |
| DMI Port Connector | |
| designation | JCI1 (internal) |
| DMI Port Connector | |
| designation | JUSB1 (internal) |
| port type | USB |
| DMI Port Connector | |
| designation | JUSB2 (internal) |
| port type | USB |
| DMI Port Connector | |
| designation | JFP1 (internal) |
| DMI Port Connector | |
| designation | JFP2 (internal) |
| DMI Port Connector | |
| designation | FDD1 (internal) |
| connector | On Board Floppy |
| DMI Port Connector | |
| designation | IDE1 (internal) |
| connector | On Board IDE |
| DMI Port Connector | |
| designation | SATA1 (internal) |
| DMI Port Connector | |
| designation | SATA2 (internal) |
| DMI Port Connector | |
| designation | SATA3 (internal) |
| DMI Port Connector | |
| designation | SATA4 (internal) |
| DMI Port Connector | |
| designation | SATA5 (internal) |
| DMI Port Connector | |
| designation | SATA6 (internal) |
| DMI Extension Slot | |
| designation | PCI1 |
| type | PCI |
| width | 32 bits |
| populated | yes |
| DMI Extension Slot | |
| designation | PCI2 |
| type | PCI |
| width | 32 bits |
| populated | yes |
| DMI Extension Slot | |
| designation | PCIE1 |
| type | PCI Express |
| width | 32 bits |
| populated | yes |
| DMI Extension Slot | |
| designation | PCIE2 |
| type | PCI Express |
| width | 32 bits |
| populated | yes |
| DMI Physical Memory Array | |
| location | Motherboard |
| usage | System Memory |
| correction | None |
| max capacity | 4 GB |
| max# of devices | 4 |
| DMI Memory Device | |
| designation | DIMM1 |
| format | DIMM |
| type | SDRAM |
| total width | 64 bits |
| data width | 64 bits |
| size | 2 GB |
| manufacturer | Manufacturer00 |
| part number | ModulePartNumber00 |
| serial number | SerNum00 |
| DMI Memory Device | |
| designation | DIMM2 |
| format | DIMM |
| type | SDRAM |
| total width | 64 bits |
| data width | 64 bits |
| size | 2 GB |
| manufacturer | Manufacturer01 |
| part number | ModulePartNumber01 |
| serial number | SerNum01 |
| DMI Memory Device | |
| designation | DIMM3 |
| format | DIMM |
| type | unknown |
| manufacturer | Manufacturer02 |
| part number | ModulePartNumber02 |
| serial number | SerNum02 |
| DMI Memory Device | |
| designation | DIMM4 |
| format | DIMM |
| type | unknown |
| manufacturer | Manufacturer03 |
| part number | ModulePartNumber03 |
| serial number | SerNum03 |
| Graphics | |
| Number of adapters | 1 |
| Graphic APIs | |
| API | NVIDIA I/O |
| API | NVIDIA NVAPI |
| Display Adapters | |
| Display adapter 0 (primary) | |
| ID | 0x1050215 |
| Name | NVIDIA GeForce GT 240 |
| Revision | A2 |
| Codename | GT215 |
| Core family | 0xA3 (GT215) |
| Cores | 96 |
| Technology | 40 nm |
| Memory type | GDDR5 (Qimonda) |
| Memory size | 512 MB |
| Memory bus width | 128 bits |
| Current Link Width | x16 |
| Current Link Speed | 2.5 GT/s |
| PCI device | bus 1 (0x1), device 0 (0x0), function 0 (0x0) |
| Vendor ID | 0x10DE (0x0000) |
| Model ID | 0x0CA3 (0x0000) |
| Revision ID | 0xA2 |
| Root device | bus 0 (0x0), device 1 (0x1), function 0 (0x0) |
| Performance Level | Current |
| Core clock | 135.0 MHz |
| Shader clock | 270.0 MHz |
| Memory clock | 324.0 MHz |
| Win32_VideoController | AdapterRAM = 0x20000000 (536870912) |
| Win32_VideoController | DriverVersion = 6.14.13.4052 |
| Win32_VideoController | DriverDate = 07/02/2014 |
| Monitor 0 | |
| Model | 919 (AOC International) |
| ID | AOC1919 |
| Serial | CJXBAJA000109 |
| Manufacturing Date | Week 40, Year 2011 |
| Size | 19.1 inches |
| Max Resolution | 1280 x 1024 @ 60 Hz |
| Horizontal Freq. Range | 30-80 kHz |
| Vertical Freq. Range | 55-75 Hz |
| Max Pixel Clock | 140 MHz |
| Gamma Factor | 2.2 |
| Video Input | 0x68 |
| Software | |
| Windows Version | Microsoft Windows XP Professional Service Pack 3 (Build 2600) |
| DirectX Version | 9.0c |
   cpuz_xp32bit.txt The following x86_64 images were made under WINE on ChaletOS linux on the same system.
cpuz_wine_64bit.txt The following x86_64 images were made under the Hiren's BootCD PE Win10 ISO on a Ventoy USB stick on the same system.
cpuz_win10_64bit.txt The following x86_64 images were made under WINE and Box64 on my Pi4.
cpuz_wine_box64.txt It could be said that CPU-X is a relative of CPU-Z.
cpux_pi4.txt Return to previous page Return to home page |
